WI Model E
Testing accuracy and precision is vital to reducing product giveaway cost. To optimise product costs, Model E is specifically designed to provide enhanced accuracy and precision in ethanol
fuel components, such as:
- Ethanol
- Water
- Methanol
- Denaturant
- Density
- Isopropanol
capture significant cost savings from improved process control
and product blending.
Download Product Details
The WI Instruments Model E is specified equipment for analyzing octane according to:
ASTM D5845:
Standard Test Method for Determination of MTBE, ETBE, TAME, DIPE, Methanol, Ethanol and tert-Butanol in Gasoline by Infrared Spectroscopy.
Features & Benefits
It is in conformance with the existing industry standard of ASTM D5845. Model E also possesses proprietary chemometrics capabilities for enhanced accuracies in all blends of fuel ethanol and pure ethanol, as compared to industry standards.
Model E's engineering team is ready to work with customers to incorporate their unique matrix, if needed, into the database to ensure high accuracy regardless of sample sources.
Leveraging on proprietary semiconductor technology, Model E eliminates the downsides from conventional FTIR analyzers (moving / fragile components, alignment issues, and sensitivity to vibrations) to provide unmatched accuracy and robustness.
Model E is designed with color-coded metrics for easy interpretation and analysis of test results. Moreover, with automated calibration, no additional software setting changes are required for different samples.
Model E Details
-
Ethanol - 0-100% mass
-
Water - 0-10% mass
-
Methanol - 0-100% mass
-
Denaturant - 0-100% mass
- Density - 0.5-2g/cm3
-
Isopropanol - 0-6% mass
-
395.1 mm X 322.3 mm X 307.5 mm
-
Approx. 5 kg
